Tiny size and light weight
Multiple image algorithms
Friendly application interface
Thermal image resolution up to 640*512
|
Model
|
TopX6
|
|
Infrared Detector
|
|
|
Resolution
|
640×512
|
|
Pixel pitch
|
12μm
|
|
Spectral range
|
8μm~14μm
|
|
NETD
|
≤30mK@25℃
|
|
Image Effect
|
|
|
Frame rate
|
50Hz
|
|
Starting time
|
≤15s
|
|
Image interface
|
Analog thermal core:CVBS &USB
Digital thermal core:MIPI&USB/DVP&USB |
|
Palette
|
13 types option(white heat,lava,red iron,light green,black heat etc)
|
|
Image algorithm
|
NUC/3DNR/DNS/DDE
|
|
Digital zoom
|
1.0~4.0x(step size 0.1)
|
|
Mirror image
|
Right &left,up &down,diagonal line
|
|
Crosshairs
|
Show,blank,moving
|
|
General
|
|
|
Communication
mode |
USB2.0/UART
|
|
Power supply
|
DC3.9~5.5V(5V commonly)
|
|
Mini power
consumption |
≤1.2W
|
|
尺寸(mm)
|
25.4x25.4(w/o lens)
|
|
Weight
|
27.5±1g(w/o lens)
|
|
Working
temperature |
-40℃-+60℃
|
|
Storage
temperature |
-45℃~+85℃
|
|
Antivibration
|
Random vibration:5.35gms,3 axis
|
|
shock resistance
|
Half sinusoid:40g/11ms,3 axis
|
|
Opical lens
|
|
|
Optional lens
|
Athermalization:9.1mm/13mm/19mm/25mm/35mm/50mm/75mm
|
|
