QS3/QS6-T
Product Features
C Series
thermtec
QS3/QS6-T
High Speed Dome & Dual Spectrum System

Support temperature measurement and detection;

Smart alarm linkage output;

IP66, 360°all-round high speed dome, close observation and measurement for indoor & outdoor scene;

Abundant interface and function, standard security design interface;

Support ONVIF, CGI, GB28181, etc.

SPECIFICATIONS

Model

QS3-T QS6-T

  • Detector Type

    Vanadium Oxide Uncooled FPA

  • Resolution

    384x288640x512

  • Spectral Range

    8~14μm

  • NETD

    ≤35mk@300K.F1

  • Focal Length

    Standard 10mmlens; optional 35mm or under

  • Focus Method

    Auto/Manual (auto focus for electric lens)

  • Color Palette

    9 color palettes

  • Temperature Range

    -20°C~+350°C

  • Temperature Accuracy

    Max (±2°C, ±2% )

  • Measurement Method

    Various rule types (area/point/line/frame etc.)

  • Image Sensor

    1/3' CMOS

  • Min. Illumination

    0.001Lux/F1.5 (color); 0.0005Lux/F1.5 (b/t)

  • Resolution

    1920x1080

  • Focal Length

    5.5~180mm 33x optics

  • Video Fusion

    PIP(within the visible video)

  • Intelligent Algorithm

    Intelligent analysis: Intrusion, line crossing, area entry & exit, motion detection, human and vehicle auto-detection, fire detection, linkage alarm output and screenshot

  • Pan Range

    0° to 360° endless

  • Tilt Range

    -20°~+90°

  • Preset

    255

  • Interoperability

    ONVIF, CGI, GB28181, third party management platform

  • Protocol

    TCP/IP, ICTP, DCHP, DNS, RTP, RTSP, RTCP, IGMP, 802.1X, ONVIF (Profiles)

  • Network Port

    1x RJ45 10M/100M Base-TX; Self-adaptive interface

  • Video Compression

    H.264,H.265

  • Communication Port

    1x RS485

  • Alarm

    1x alarm out

  • Power

    Power Supply: AC24V; Power Consumption: <30W

  • Work Temperature

    -20°C~+60°C; <90%RH

  • Net Weight

    6kg

  • Dimension

    φ210mmx310mm

  • Protection Class

    IP66; Anti-thunder: 3KV; Surge protection
