M507C
Product Features
C Series
thermtec
M507C
NST thermal imaging analog core

Non-shutter technology

Rapid start within 3s

Ultra-low latency output

Surroundings well-adapted

Optional video output types

SPECIFICATIONS
Items
M507C
Interface
Detector
Uncooled VOXFPA
Resolution/
Pixel pitch
640x510/12μm
Power interface
DC:+2.5V～5.5V
NETD
≤35mk@F1.0,300K
Analogue
video
Double channels
Spectral
range
8~14μm
Series port
RS232
Focus
Method
Fixed lens
Digital video
8 Bit/14Bit(50Hz)
Focal
length
9/15/19/25/40/50mm etc
Keyboard
4 buttons keyboard
  Image Effect
  General
adjustment
Auto adjustment for contrast
ratio &brightness &acutance
Uniformity
calibration
NST
Working
temperature/
humidity
-20℃~+60℃,5%～95%RH
Zoom
2x,4x
Storage
temperature
-40℃~+60℃
Noise
reduction
Digital filter
Power
Consumption
1.3w
Palette
9 Pseudo color palettes
changeable
Reverse
polarity
protection
Yes
Resolution
768*576
Starting time
<5s
mirroring
Horizontal &vertical
Size
42.5mm*41mm*19.3mm
Polarity
inversion
Black hot &white hot
Weight
<35g(w/o lens)
View More Download File
