HM2-T
Product Features
C Series
thermtec
HM2-T
Dual Spectrum Thermal Bullet Camera

Support temperature measurement and detection;

Embedded intelligent analysis algorithm: motion detection, intrusion, line crossing, tripwire, moving track and target enhancement, etc.;

Built-in smart sound & light alarm module;

IP67, abundant interface and function;

Applicable to complex environment: rain, night, snow, smog, etc.;

Excellent dual images fusion (visible and thermal images) technology.

SPECIFICATIONS

Model

HM2-T

  • Detector Type

    Vanadium Oxide Uncooled FPA

  • Resolution

    256x192

  • Spectral Range

    8~14μm

  • NETD

    ≤35mk@300K.F1

  • Focal Length

    Optional 3/7/10mm

  • Focus Method

    Athermalization free focus

  • Color Palette

    9 color palettes

  • Sound & Light Alarm

    Yes

  • Temperature Range

    -20°C~+250°C

  • Temperature Accuracy

    Max (±5°C, ±5% )

  • Measurement Method

    Various rule types (area/point/line/frame etc)

  • Image Sensor

    1/2.8”CMOS

  • Resolution

    2592x1536

  • Focal Length

    According to lens match: 4/6/8mm

  • IR Range

    50m

  • Video Fusion

    Yes

  • PIP

    Yes

  • Intelligent Algorithm

    Intelligent analysis: Intrusion, line crossing, area entry & exit, motion detection, human and vehicle auto-detection, fire detection, linkage alarm output and screenshot

  • User Management

    Up to 9; 3levels: Administrator, Operator, General

  • Multi-stream

    Simultaneous output 3 streams (third stream is dual fusion image)

  • Security

    Authorized username and password; Attached MACaddress; Encrypted HTTPS; IP filtration

  • Interoperability

    ONVIF; CGI; third party management platform

  • Protocol

    TCP/IP, ICMP, HTTP, DCHP, DNS, RTP, RTSP, RTCP, IGMP, 802.1X, ONVIF (ProfileS)

  • Network Port

    1x RJ45 10M/100M Base-TX; Self-adaptive interface

  • Video Compression

    H.264, H.265

  • Communication Port

    1xRS485

  • Alarm

    1xalarm in; 1xalarm out

  • Power Supply

    DC12V, POE+

  • Power Consumption

    小Basic: <2W(IR off )

  • Work Temperature

    -20°C~+60°C;<90%RH

  • Storage Temperature

    –45°C ~ +75°C

  • Net Weight

    <1.6kg

  • Dimension

    Length: 276.9mm (non sunshade cover)

  • Protection Class

    IP67
