High image quality: 640x512@12μm;
Powerful behavior analysis algorithm: Line crossing, intrusion, region entry & exit;
Thermal image smart function: Multiple targets types detection;
Excellent image enhancement: AGC, NUC, IDE, HDR, DNR;
Fire prevention: Advanced fire detection algorithm;
Light weight design: high speed rotation, low power consumption, easier installation;
Unique material: More suitable for some special scenes, such as high salinity, acidity environment;
Superior environmental adaptability: Applicable for extreme weather, including darkness, rain, fog, smog and etc.;
Complete customizability: 4G wireless transmission and etc. in option
Thermal Module
EVE3 EVE6
Resolution
384x288640x512
Pixel pitch
12µm
Spectral range
8-14µm
NETD
≤35mK
Focal Length
7mm10mm17mm25mm35mm
FOV - EVE3
36.4x27.726x19.615.4x11.610.5x7.97.5x5.7
FOV - EVE6
60.7x48.543.3x34.625.7x20.617.5x1412.5x10
F Number
F1.0
Focus Method
Motorized
Image Sensor
Uncooled FPA
Color Palette
14 color palettes
Focal Length
4mm8mm12mm16mm16mm
FOV
80x56.741.2x23.628x23.921x1821x18
F-Number
F1.6
Focus Method
Fixed
Image Sensor
1/2.8” Progressive Scan CMOS
Resolution
4MP
Min. Illumination
Color: 0.01Lux@(F1.5,AGCON) B/W:0.001Lux@(F1.5, AGCON)
Thermal image process algorithm
AGC, NUC, IDE, HDE, DNR
Picture in Picture
Support
Bi-spectrum Image Fusion
Display the details of optical channel on thermal channel
VCA
4 VCA types (motion detection, cross line, intrusion, area entry and exit), max. 10 VCA rules
Temperature Measurement
3 temperature measurement rule types, 30 rules in total (10 points, 10 areas, and 10 lines).
Temperature Range
-20°C~+ 150°C (-4 °F ~ + 302°F)
Temperature Accuracy
± 8 °C (± 14.4 °F)
Fire Detection
Support
Thermal image smart function
Human, vehicles, vessels, animals detection
Main-Stream (Visible)
25fps (2592*1536,1920*1080,1280*720)
Sub-stream (Visible)
25fps (1280*720,768*576,640*480)
Main-Stream (Thermal)
25fps (1280*720,768*576,640*480,384*288,352*288)
Sub-stream (Thermal)
25fps (768*576,640*480,384*288,352*288)
Video Compression
H.265 / H.264
Protocols
IPv4, HTTP, HTTPS, FTP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, ONVIF
API
SDK, third-party management platform, ONVIF and CGI
Simultaneous Live View
6 users
User/Host level
Up to 10 users, 3 levels: Administrator, Operator, General
Security
Support password protection, bonding MAC ID, IP filtration
Client
Support ThermTec platform, third-party VMS by ONVIF, etc.
Web Browser
Google Kernel Browser, Edge
Alarm Input
1ch
Alarm Output
1ch
Communication Interface
RJ45 10 M/100 M self-adaptive Ethernet interface RS-485 interface
Web Client Language
English
Power Supply
DC 12V
Power Consumption
15W
Work Temperature/ Humidity
-20°C~+60°C (-4°F~+140°F), <95%RH
Protection Level
IP66TVS 6000V lightning protection, surge protection, voltage transient protection
Dimension
340mm×202mm×152mm
Weight
≤3.5Kg
/
