Surroundings well-adapted
High shock resistance
Compact design
Non-shutter technology
Optional video output types
|
Items
|
ATOM505C
|
Interface
|
||
|
Detector
|
Uncooled VOX FPA
|
|||
|
Resolution/
Pixel pitch |
640x510/12μm
|
Power interface
|
DC:+2.5V～5.5V
|
|
|
NETD
|
≤35mk@F1.0,300K
|
Analogue video
|
Double channels
|
|
|
Spectral
range |
8~14μm
|
Series port
|
RS232
|
|
|
Focus
Method |
Fixed lens
|
Digital video
|
BT656(768*576)or Digital
parallel |
|
|
Focal
length |
9/15/19/25/40/50mm etc
|
Keyboard
|
4 buttons keyboard
|
|
|
Image Effect
|
General
|
|||
|
adjustment |
Auto adjustment for contrast
ratio &brightness &acutance |
Working
temperature/ humidity |
-20℃~+45℃,5%~
95%RH |
|
|
Uniformity
calibration |
NST
|
Storage
temperature |
-45℃~+65℃
|
|
|
Zoom
|
2x,4x
|
Power
Consumption |
1.2w
|
|
|
Noise
reduction |
Digital filter
|
Shock
resistance |
6000J
|
|
|
Palette
|
9 Pseudo color palettes
changeable |
Size
|
25.9mm*28mm*28mm
|
|
|
Resolution
|
768*576
|
640*480
|
Weight
|
<33g
|
|
Items
|
ATOM505C
|
Interface
|
||
|
Detector
|
Uncooled VOX FPA
|
|||
|
Resolution/
Pixel pitch |
640x510/12μm
|
Power interface
|
DC:+2.5V～5.5V
|
|
|
NETD
|
≤35mk@F1.0,300K
|
Analogue video
|
Double channels
|
|
|
Spectral
range |
8~14μm
|
Series port
|
RS232
|
|
|
Focus
Method |
Fixed lens
|
Digital video
|
BT656(768*576)or Digital
parallel |
|
|
Focal
length |
9/15/19/25/40/50mm etc
|
Keyboard
|
4 buttons keyboard
|
|
|
Image Effect
|
General
|
|||
|
adjustment |
Auto adjustment for contrast
ratio &brightness &acutance |
Working
temperature/ humidity |
-20℃~+45℃,5%~
95%RH |
|
|
Uniformity
calibration |
NST
|
Storage
temperature |
-45℃~+65℃
|
|
|
Zoom
|
2x,4x
|
Power
Consumption |
1.2w
|
|
|
Noise
reduction |
Digital filter
|
Shock
resistance |
6000J
|
|
|
Palette
|
9 Pseudo color palettes
changeable |
Size
|
25.9mm*28mm*28mm
|
|
|
Resolution
|
768*576
|
640*480
|
Weight
|
<33g
|
/
